NVR DAHUA 8 CHANNEL DHI-NVR1108HS-S3/H

Item Code: 10159

Dahua-NVR1108HS-8P-S3/H System Overview

Dahua-NVR1108HS-8P-S3/H 8 Channel Compact 1U 8PoE Lite H.265 Network Video Recorder. This network video recorder is a highly cost-effective product, providing functions such as local live view, multi-screen display, real-time storage on local HDD, fast operation by mouse, and remote management and control.

Dahua-NVR1108HS-8P-S3/H Specification

System
Main Processor: Industrial-grade embedded processor
Operating System: Embedded Linux
Operation Interface: Web/operating in local GUI

Video
Access Channel: 8 channels
Network Bandwidth: 80 Mbps for access, 80 Mbps for storage, and 60 Mbps for forwarding.
Resolution: 8MP/5MP/4MP/3MP/1080P/720P/D1/CIF
Decoding Capability:
1–ch@8MP (30FPS) or 1–ch@5MP (30FPS) or
2–ch@4MP (30FPS) or 2–ch@3MP (30FPS) or
4–ch@1080P(30FPS)8–ch@720P(30FPS)
Video Output: 1 VGA/1 HDMI simultaneous video output, maximum resolution 1080P
Multi-screen Display: 1/4/8/9
Third-Party Camera Access: Onvif, RTSP

Compression
Video: Smart H.265+/Smart H.264+/H.265/H.264
Audio: PCM/G711A/G711U/G726/AAC

Network
Network Protocol: HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, P2P
Mobile Phone Access: IDMSS (iOS), GDMSS (Android)
Access Standard: ONVIF (profile T/profile S/profile G), CGI, SDK
Browser: Chrome, IE9 or above, Firefox

Alarm
General Alarm: Motion detection, privacy masking, video loss, PIR alarm, IPC alarm
Anomaly Alarm: Front-end device going offline, storage error, full storage, IP conflict, MAC conflict, login lock, network security anomaly
Alarm Linkage: Video recording, snapshot, log, preset, tour

External Port
HDD:
1 SATA 2.0 port, up to 8 TB for a single HDD. The
maximum HDD capacity varies with the environment
temperature:
USB: 1 front USB 2.0 port, 1 rear USB 2.0 port
HDMI: 1
VGA: 1
RCA Input: 1
RCA Output: 1
Alarm: None
Network: 1 RJ–45 port (10/100 Mbps), 8 RJ–45 ports with PoE
power supply: (10/100 Mbps)

General Parameter
Power Supply: DC48V/53V, 2A/1.8A
Power Consumption:
The total output of NVR is ≤ 10W (without HDD)
The total output power of PoE is 72W, and the maximum output
The power of a single port is 25.5W
Net Weight: 0.84 kg (1.85 lb)
Gross weight: 1.98 kg (4.37 lb)
Product Dimensions: 260 mm×225 mm×47.6 mm (W × L × H)
Box Dimensions: 87 mm×331 mm×312 mm (W × L × H)
Operating Temperature: -10°C to 45°C (+34°F to +113°F)
Storage Temperature: 0°C to 40°C (+32°F to +104°F)
Operating Humidity: 10%~93%
Storage Humidity: 30%~85%
Operating Altitude: 3000 m (9843 ft)
Installation: Desktop mounting
Certification: CE/FCC
