* The parameters and datasheets below can only be applied to1509-S2 series.

*In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version.

> Max 25 fps@5MP (16:9 video output)

> 120 dB true WDR, 3D NR
> 24/7 color imaging
> 40 m illumination distance
> CVI/CVBS/AHD/TVI switchable
> Built-in mic (-A)
> 3.6 mm fixed lens (2.8 mm optional)
> IP67, 12 V DC

> 4-MP 1/2.9″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688× 1520)@20 fps, and supports (2560 × 1440)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and the max. illumination distance is 50 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in Mic.

> 12 VDC/PoE power supply, 12 VDC power output, max. current 165 mA, easy for installation.

> IP67 protection.

> SMD Plus.
