Experience efficiency and reliability with the GIGABYTE BUILD bundle, pairing the Intel Core i3-10100 with the GIGABYTE H510M-K. Elevate your computing setup for responsive performance and seamless multitasking. Upgrade now!
Supports 11th/10th Gen Intel® Core™ Processors
Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
8-Channel HD Audio with High Quality Audio Capacitors
NVMe PCIe Gen3 x4 2280 M.2 Connector
GbE LAN with Bandwidth Management
Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
GIGABYTE APP Center, Simple and Easy Use
Anti-Sulfur Resistors Design
AMD Ryzen™ 7 5700G
# of CPU Cores: 8
Base Clock: 3.8GHz
Default TDP: 65W
# of Threads: 16
L2 Cache: 4MAMD Configurable TDP (cTDP): 45-65W
CPU Socket: AM4
Product Line: AMD Ryzen™ 7 5000 G-Series Desktop Processors with Radeon™ Graphics
Max. Boost Clock: Up to 4.6GHz
MSI B450M-A PRO MAX
AMD AM4 motherboard inspired from architectural design, with Core Boost, DDR4 Boost, Turbo M.2, USB 3.2 Gen1
Supports 1st, 2nd and 3rd Gen AMD® Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD® Ryzen™with Radeon™ Graphics / Athlon™ with Radeon™ Vega Graphics and A-series / Athlon™ X4 Desktop Processors for Socket AM4
Supports DDR4 Memory, up to 4133 (OC) MHz
Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs.
Audio Boost: Reward your ears with studio grade sound quality.
X-Boost: Software that auto-detects and allows you to boost the performance of any storage or USB device.
Core Boost: With premium layout and fully digital power design to support more cores and provide better performance.
The AMD Ryzen 7 5700G is a desktop processor with 8 cores, launched in April 2021. It is part of the Ryzen 7 lineup, using the Zen 3 (Cezanne) architecture with Socket AM4. Thanks to AMD Simultaneous Multithreading (SMT) the core-count is effectively doubled, to 16 threads. Ryzen 7 5700G has 16 MB of L3 cache and operates at 3.8 GHz by default, but can boost up to 4.6 GHz, depending on the workload. AMD is making the Ryzen 7 5700G on a 7 nm production node using 10,700 million transistors. The silicon die of the chip is not fabricated at AMD, but at the foundry of TSMC. You may freely adjust the unlocked multiplier on Ryzen 7 5700G, which simplifies overclocking greatly, as you can easily dial in any overclocking frequency.
With a TDP of 65 W, the Ryzen 7 5700G consumes typical power levels for a modern PC. AMD’s processor supports DDR4 memory with a dual-channel interface. The highest officially supported memory speed is 3200 MT/s, but with overclocking (and the right memory modules) you can go even higher. For communication with other components in the computer, Ryzen 7 5700G uses a PCI-Express Gen 3 connection. This processor features the Radeon Vega 8 integrated graphics solution.
Hardware virtualization is available on the Ryzen 7 5700G, which greatly improves virtual machine performance. Programs using Advanced Vector Extensions (AVX) can run on this processor, boosting performance for calculation-heavy applications. Besides AVX, AMD is including the newer AVX2 standard, too, but not AVX-512.
AMD Ryzen 5 5600G
AMD R5 5600G
The AMD Ryzen 5 5600G is a Zen 3-based, desktop-grade APU featuring the Radeon Vega 7 graphics adapter. This Ryzen 5 was unveiled in H1 2021. It features six SMT-enabled CPU cores for 12 threads in total, running at 3.9 GHz to 4.4 GHz.
The CPU ships with AMD’s Wraith Stealth cooler as long as it’s not an OEM version.
Architecture
Zen 3-based processors bring a moderate performance boost over Zen 2 generation CPUs. Core counts are left where they were before, while per-MHz performance is getting several percentage points higher.
Ryzen 5 5600G’s CPU cores have access to 16 MB of L3 cache. The processor is compatible with DDR4-3200 RAM and has plenty of PCI-Express 3.0 lanes for connecting graphics cards, SSDs and other devices. Four PCI-Express 3.0 lanes allow for read/write rates of up to 3.9 GB/s, provided a sufficiently fast NVMe SSD is used. PCI-Express 4.0 spec is not supported here, since Ryzen 5 5600G is pretty much a laptop-grade SoC in disguise rather than a “proper” desktop chip, like a Ryzen 5 5600X.
You can replace this Ryzen with a faster CPU easily as it uses AMD’s AM4 socket interface. Another way to get a performance boost would be to overclock the CPU, which is easy to do with AMD’s very own software (many motherboard vendors offer overclocking software of their own as well).
AMD AM4 motherboard inspired from architectural design, with Core Boost, DDR4 Boost, Turbo M.2, USB 3.2 Gen1
Supports 1st, 2nd and 3rd Gen AMD® Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD® Ryzen™with Radeon™ Graphics / Athlon™ with Radeon™ Vega Graphics and A-series / Athlon™ X4 Desktop Processors for Socket AM4
Supports DDR4 Memory, up to 4133 (OC) MHz
Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs.
Audio Boost: Reward your ears with studio grade sound quality.
X-Boost: Software that auto-detects and allows you to boost the performance of any storage or USB device.
Core Boost: With premium layout and fully digital power design to support more cores and provide better performance.
