Item Code: 11672
4MP Full-color Fixed-focal Bullet Wizsense Network Camera
> 4-MP 1/2.9″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688× 1520)@20 fps, and supports (2560 × 1440)@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in warm light and the max. illumination distance is 50 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in Mic.
> 12 VDC/PoE power supply, 12 VDC power output, max. current 165 mA, easy for installation.
> IP67 protection.
> SMD Plus.
Item Code: 11664
2MP Smart Dual Light HDCVI Fixed-focal Eyeball Camera
* The parameters and datasheets below can only be applied to1200-S6-IL series.
* In order to use the Smart Dual Light HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000004.1.R.220323 or later version.
> Max. 30 fps@1080p.
> 3D NR.
> Smart Dual Light.
> 20 m illumination distance.
> Super Adapt.
> Built-in mic.
> 3.6 mm fixed lens (2.8 mm optional).
> CVI/CVBS/AHD/TVI switchable.
> IP67, 12 VDC.
Item Code: 11663
2MP Smart Dual Light HDCVI Fixed-focal Bullet Camera
* The parameters and datasheets below can only be applied to1200-S6-IL series.
* In order to use the Smart Dual Light HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000004.1.R.220323 or later version.
> Max. 30 fps@1080p.
> 3D NR.
> Smart Dual Light.
> 20 m illumination distance.
> Super Adapt.
> Built-in mic.
> 3.6 mm fixed lens (2.8 mm optional).
> CVI/CVBS/AHD/TVI switchable.
> IP67, 12 VDC.
Item Code: 11593
* The parameters and datasheets below can only be applied to ME1509-S2 series.Intelligent Voice Alarm function which can be used with Scheduled AI of AI XVR is only available for TiOC 2.0 camera.
* In order to use the 5MP 16:9 and the Smart Dual Light HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000004.1.R.220323 or later version.
> Max 25 fps@5 MP (16:9 video output).
> 120 dB true WDR, 3D NR.
> Smart Dual Light.
> Protection Against Red-Blue Light Interference.
> Active deterrence with red blue light, siren and alarm out interface.
> 40 m illumination distance.
> Super Adapt.
> Built-in MIC.
> 3.6 mm fixed lens (2.8 mm optional).
> CVI/CVBS/AHD/TVI switchable.
> IP67, 12 VDC.
Item Code: 11592
* The parameters and datasheets below can only be applied to ME1509-S2 series.Intelligent Voice Alarm function which can be used with Scheduled AI of AI XVR is only available for TiOC 2.0 camera.
* In order to use the 5MP 16:9 and the Smart Dual Light HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000004.1.R.220323 or later version.
> Max 25 fps@5 MP (16:9 video output).
> 120 dB true WDR, 3D NR.
> Smart Dual Light.
> Protection Against Red-Blue Light Interference.
> Active deterrence with red blue light, siren and alarm out interface.
> 40 m illumination distance.
> Super Adapt.
> Built-in MIC.
> 3.6 mm fixed lens (2.8 mm optional).
> CVI/CVBS/AHD/TVI switchable.
> IP67, 12 VDC.
> Quick-to-install eyeball saves installation time.
Item Code: 11591
2MP Smart Dual Light Active Deterrence HDCVI Bullet Camera
* The parameters and datasheets below can only be applied to1239-S2 series. Intelligent Voice Alarm function which can be used with Scheduled AI of AI XVR is only available for TiOC 2.0 camera.
* In order to use the Smart Dual Light HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000004.1.R.220323 or later version.
> Active deterrence with red blue light, siren and alarm out interface.
> Max. 30 fps@1080p.
> 130 dB true WDR, 3D NR.
> Smart Dual Light.
> 40 m illumination distance.
> Super Adapt, Built-in MIC.
> 3.6 mm fixed lens (2.8 mm optional).
> CVI/CVBS/AHD/TVI switchable.
> IP67, 12 VDC.
Item Code: 11590
2MP Smart Dual Light Active Deterrence HDCVI Eyeball Camera
* The parameters and datasheets below can only be applied to1239-S2 series. Intelligent Voice Alarm function which can be used with Scheduled AI of AI XVR is only available for TiOC 2.0 camera.
* In order to use the Smart Dual Light HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000004.1.R.220323 or later version.
> Active deterrence with red blue light, siren and alarm out interface.
> Max. 30 fps@1080p.
> 130 dB true WDR, 3D NR.
> Smart Dual Light.
> 40 m illumination distance.
> Super Adapt, Built-in MIC.
> 3.6 mm fixed lens (2.8 mm optional).
> CVI/CVBS/AHD/TVI switchable.
> IP67, 12 VDC.
Item Code: 11586
5MP Smart Dual Light HDCVI Fixed-focal Eyeball Camera
* The parameters and datasheets below can only be applied to1500-IL series.
* In order to use the 5MP 16:9 and the Smart Dual Light HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000004.1.R.220323 or later version.
> Max 25 fps@5MP (16:9 video output).
> Smart Dual Light.
> 20 m illumination distance.
> Super Adapt.
> Built-in MIC.
> 3.6 mm fixed lens (2.8 mm optional).
> CVI/CVBS/AHD/TVI switchable.
> IP67, 12 VDC.
